DJI Inspire 2 Drone FPV RC Quadcopter with 4K Video,Spotlight Pro,intelligent Flight Modes,TapFly, With Zenmuse X4S or X5S

Aerial Photography: Yes
Connectivity: APP Controller,Wi-Fi Connection,Remote Control
Camera Integration: Camera Included
Gyro: DJI
DJI Model: inspire 2
Brand Name: DJI
Action Time: 25min
Pixels: 12 million
Camera Features: 1080p HD Video Recording,4K HD Video Recording
Control Channels: 12 Channels & Up
Remote Distance: 7000m
Frequency: 2.400 - 2.483 GHz ;5.725 - 5.850 GHz
Main Rotor Diameter: DJI 1550T
FPV Operration: Yes
Model Number: DJI Inspire 2
Sensor Size: 2/3 inches
Optical Zoom Ratio: 10x and below
Max Flight Time: Approx. 27 min (with Zenmuse X4S)
Obstacle Sensing Range : 2.3-98.4 feet (0.7-30 m)
Video Output Ports : USB, HDMI
Dual User Capability: Host-and-Slave connection
Max Mobile Device Width : 170 mm
Propeller Model : DJI 1550T
Model: T650

AIRCRAFT

What is the Inspire 2’s maximum flight speed?

Max Ascent Speed 6m/s (Sport Mode);
Max Descent Speed: Vertical, 13.1 ft/s (4 m/s); Tilt, 13.1-29.5 ft/s (4-9 m/s)
Default tilt is 13.1 ft/s (4 m/s), can be set in-app.
Max Speed 26m/s, 58 mph (94 kph, flight forward in S-mode).

What is the Inspire 2’s maximum flight?

Up to 25 minutes with Zenmuse X5S. Up to 27 minutes with Zenmuse X4S.

What cameras and gimbals is the Inspire 2 compatible with?

The Inspire 2 currently supports the Zenmuse X4S and Zenmuse X5S.

Does the Inspire 2 come with camera and gimbal included?

No. Please purchase your gimbal and camera separately.

Does the Inspire 2 have an Obstacle Avoidance system?

Yes. Its Forward Vision System is capable of detecting obstacles up to 30 meters ahead, while the upward facing infrared sensors can sense obstacles within a 5 meter range.

Can I use the Inspire 1 remote controller with the Inspire 2?

No. You will need to use an Inspire 2 remote with your Inspire 2 aircraft.

Does the Inspire 2 support Master and Slave remote controllers?

Yes. The maximum effective distance between the Master and Slave controllers is 100 meters, and both controllers will receive the same HD live view.

Does the Inspire 2 support older Zenmuse camera gimbals?

Currently, only the new Zenmuse X4S and Zenmuse X5S are supported.

Does the Inspire 2 come with a Micro SD card?

Yes. Included in the box is a 16GB Micro SD card. It supports SD cards up to 128GB.

Which Micro SD cards are supported?

Currently supported Micro SD cards are:
Sandisk Extreme 32GB UHS-3 V30 MicroSDHC;
Sandisk Extreme 64GB UHS-3 V30 MicroSDXC;
Panasonic 32GB UHS-3 MicroSDHC;
Panasonic 64GB UHS-3 MicroSDXC;
Samsung PRO 32GB UHS-1 MicroSDHC;
Samsung PRO 64GB UHS-3 MicroSDXC;
Samsung PRO 128GB UHS-3 MicroSDXC.

What are the dimensions of the Inspire 2?

L:42.7cm x H:31.7cm x W:42.5cm without propellers (landing mode).

What type of motors and propellers does the Inspire 2 use?

The Inspire 2 has 3512 motors and 1550T propellers.

Does the Inspire 2 come with Highland propellers?

No, please purchase the Highland propellers separately.

Has the Inspire 2’s propulsion system been improved over the Inspire 1?

Yes. The Inspire 2 uses 3512 motors and 1550T propellers. The max thrust for each rotor reaches up to 2kg.
Thousands of hours have been spent on testing to ensure top safety and reliability.

Can I carry the Inspire 2 Intelligent Flight Battery onto a commercial airplane?

The Inspire 2 Intelligent Flight Battery has a capacity 97.5Wh. Most airlines allow carrying
batteries below 100 Wh in carry-on luggage. However, as regulations may vary across airlines and regions, please contact your airline or the regulatory body of your destination.

REMOTE CONTROLLER

What’s the highlight features of the Inspire 2’s remote controller and video transmission system?

The new dual-band Lightbridge HD video transmission system has a maximum transmission distance of 7 km*.
The video feed from the FPV camera and main camera (1080p or 720p) can be viewed simultaneously through the Picture in View feature. The dual-band system is consists of 2.4GHz ISM and 5.8GHz ISM**, giving the Inspire 2 stronger resistance against interference.
*Unobscured, free of interference, FCC compliant.
**In accordance with local law and regulations, 5.8GHz is not available in some countries.

How long does it take to charge a remote controller? How long does it last on a full charge?

The remote controller is equipped with a 6,000mAh LiPo 2S battery. Fully charging the Inspire 2 remote controller takes approximately 3 hours.
It can be used for approximately 4 hours after being fully charged.

What is the largest tablet that will fit in the remote controller’s mobile device mount?

The mount can support an iPad Air or other similar-sized tablet. Tablets should be no more than 170mm tall.

What kind of working mode does the remote controller support?

Open the DJI GO app, click the remote controller icon and enter to Settings.
You can choose MODE1, MODE2, MODE3, Custom and more under Stick Mode.

Does the Inspire 2 remote controller come with a monitor?

No. The remote controller has a mobile device holder for smartphones and tablets. You can also buy the DJI CrystalSky monitor.

Is there any specific conditions necessary for the Inspire 2 to reach a 7km video transmission range?

The distance here refers to environments free of obstructions and interference, under FCC compliant specifications.

What is the maximum control distance between Master remote controller and Slave remote controller?

The Master and Slave remote controllers can maintain a connection at distances up to 100 meters.

Does the remote controller have a training port?

There is no training port on the Inspire 2 remote controller.

What is the latency of the Inspire 2’s video transmission system?

Below 220ms.

BATTERY

How long does it take fully charge the batteries? Do I get a standard Battery Charger together with the aircraft?

You will get a 180W Battery Charger and a Battery Charging Hub in the box with your Inspire 2.
When connecting the standard Battery Charger to the Battery Charging Hub, it takes about 90 minutes to charge 2 batteries and 180 minutes to charge 4 batteries.

Can I use batteries with different charge levels?

The Inspire 2 can take off if the power discrepancy of the two batteries is within 13%. If it is unable to take off, the DJI GO app will inform you that “the power discrepancy in the two batteries is too large”.

What will happen if an error occurs in one battery?

The Inspire 2 continuously checks battery status and will notify you through the DJI GO app if a battery malfunctions.
In this case, please land the aircraft immediately.

Why do I need to pair the two batteries?

By charging and discharging a pair of batteries together you will maximize flight time and battery life.

How can I pair up two batteries?

Please match batteries on the battery interface of DJI GO app.

How do I know that the batteries are correctly mounted?

You will hear the Exit button click to confirm successful mounting of each battery.
Other signs is that the button will have less give when you tap it, and that the batteries will not detach when pulled.
The DJI GO app also will not inform you of errors and show a full status for each battery when properly mounted.

What should I do with the batteries if I am not going to use them for a long time? What’s the maximum duration that I can store them?

It is recommended that you keep the Intelligent Flight Batteries charged to 50% when storing them.
If storing for a long period of time, we also recommend that you fully discharge them every 3 months.

CAMERAS

Can I use Adobe CinemaDNG and Apple ProRes after purchasing the Zenmuse X5S?

No, you will need to purchase a DJI License Key to enable these formats.

Does the Zenmsue X4S support the Adobe CinemaDNG and Apple ProRes?

No.

What is the resolution of Inspire 2’s forward-facing camera?

640 x 480px.

Is the pitch of the FPV camera controllable?

Yes. Press and hold the C2 button, and at the same time use the left dial to control the pitch. The roll axis is not controllable.

OTHER

Is a SSD (Solid State Drive) included in the box with the Inspire 2?

No. You need to purchase the DJI CINESSD and DJI CINESSD Station card reader separately.

What capacities is the DJI CINESSD available in?

120GB and 480GB.

Does Inspire 2 have any redundant components?

Yes. Many key parts of the Inspire 2 are designed with redundancy, including IMU sensors and barometers.
The Inspire 2 flight controller monitors and analyses the redundancy data in real time, to ensure that flight data is correct.

Does the Inspire 2 have the Return to Home (RTH) function?

Yes. During RTH, the Inspire 2 is able to collect information about the environment and automatically plan the best path back home.
Being able to detect obstacles 200m away, it also restores communication faster with the remote controller during RTH after losing signal, so as to make RTH safe and successful.

What is the minimum altitude required for initiating ActiveTrack?

To use ActiveTrack, you should keep your Inspire 2 at least 2m above the ground and set the aircraft to P-Mode.

GIMBAL Model : ZENMUSE X4S&ZENMUSE X5S
